Gain:
-80 to +15dB, 0,1dB steps
Polarity: normal / inverted
Delay:
0 to 250 ms (Shared between User and Group settings)
PEQ:
12 x PEQ. Each PEQ can be set to a choice of 16 fi lter types: Bell-Sym, Bell-Asym,
Notch, Low-Shelf 6dB or12dB, High-Shelf 6dB or 12db, All-Pass 90° or 180°, High Pass 6dB, or 12dB,
High-Pass VariQ 12dB, Low-Pass 6dB or 12dB, Low-Pass Vari-Q 12dB, Band-Pass
HP/LP filters:
Bessel , Butterworth and Linkwitz Riley with slopes from 6 to 48 dB/oct
Limiter:
Peak voltage, RMS voltage
Groups:
Six global processing group overlays which can link any amplifier channel in the network
Gain:
-80 to +15dB, 0,1dB steps
Delay: 0 to 250 ms (Shared between User and Group settings)
PEQ:
12 x PEQ. Each PEQ can be set to a choice of 16 fi lter types: Bell-Sym, Bell-Asym,
Notch, Low-Shelf 6dB or12dB, High-Shelf 6dB or 12db, All-Pass 90° or 180°,
High Pass 6dB, or 12dB, High-Pass VariQ 12dB, Low-Pass 6dB or 12dB, Low-Pass Vari-Q12dB, Band-Pass
Gain:
-80 to +15dB, 0,1dB steps
Polarity:
normal / inverted
Delay:
0 to 250 ms (Shared between User and Group settings)
PEQ:
12 x PEQ. Each PEQ can be set to a choice of 16 fi lter types: Bell-Sym, Bell-Asym,
Notch, Low-Shelf 6dB or12dB, High-Shelf 6dB or 12db, All-Pass 90° or 180°, HighPass 6dB,
or 12dB, High-Pass VariQ 12dB, Low-Pass 6dB or 12dB, Low-Pass Vari-Q 12dB, Band-Pass
FIR filters:
768 taps per channel
HP/LP filters:
Bessel , Butterworth and Linkwitz Riley with slopes from 6 to 48 dB/oct
Limiter:
Peak voltage, RMS voltage
