4 Channel Amplifier with dual DSP

Intelli-Power 10

THE PERFECT BALANCE OF POWER AND CONTROL

Intelli-Power 10 combines a powerful 4 x 2500W with APEX’s legendary Intelli-Series DSP to offer a complete powered system management and loudspeaker processing solution. Featuring full plug ‘n play Dante audio networking integration, Intelli-Power 10 can be remotely configured, monitored and controlled using our acclaimed Intelli-Ware software.

Applications

Intelli-Power 10 is designed as a powered solution for signal routing and distribution, room equalisation, speaker and driver time alignment and crossover implementation. In addition to serving at FoH and Monitors on tours and festivals and in fixed installations, Intelli-Power 10 is also eminently suitable as a room equaliser, active crossover and /or audio DA in a studio or cinema.

Key features

4 x 2500W Amplifier

Intelli-Power 10 is built around APEX’s proprietary 4 channel, Class D amplifier design. The amplifier’s D/A conversion employs direct drive technology, enhancing the impulse response for accurate bass response.

Dante

Intelli-Power 10 has a built-in, fully redundant Dante module with rugged Neutrik locking etherCON connectors, enabling easy integration with a Dante network.

192 kHz

Featuring internal processing selectable from 44.1kHz to 192 kHz, Intelli-Power 10 provides full compatibility with both standard and high-end sample rate formats. Switchable convertors are provided on the inputs, making it easy to work with equipment operating at different sample rates.

IIR AND FIR

The Intelli-series is packed with all the system management tools necessary for comprehensive system alignment and EQ, through to the provision of IIR and custom FIR based crossovers.

Auto ip

Intelli-Power 10 is designed to interface easily into any Ethernet network via internal 3-way Ethernet switches. Both automatic IP (DHCP) and static IP configuration is provided as standard for plug ‘n play connectivity.

Synchronisation

Four sync options are available: Dante, AES A/B, AES C/D and internal. Intelli-Power 10 has a three-tiered redundancy approach, automatically reverting to another source (defined by the user) if any source is lost, ensuring no loss in audio.

AES

Intelli-Power 10’s I/O is selectable in pairs as analogue, AES/EBU or Dante audio network, allowing a mix of audio formats to be accommodated simultaneously.

Two ways to control

Intelli-Power 10 can be configured and adjusted on the fly via its front panel controls and LCD screen, with straightforward, icon-driven menus helping you to get straight to the parameter you need. Alternatively, APEX’s acclaimed Intelli-Ware software provides fast, intuitive control from your PC.

SMAART / LIVECAPTURE INTEGRATION

Intelli-Ware comes complete with an analyser/bridge feature, enabling control of all commonly used sound measurement tools found in WaveCapture’s Live-Capture and Rational Acoustics’ Smaart 7/8, all directly from within the software.
